Use-Case Specification--Relations Tab

Figure 46 Use-Case Specification--Relations Tab

Refer to the descriptions in the Introduction to Specifications chapter for information on the specification elements not covered in the following section.

Relations

The Relations tab lists all the association relationships that correspond to the selected use case. The client and supplier names and type icons are displayed to the right of the relation name. Double-clicking on any column in a row displays the element's specification.

---

Generalize Specification

A Generalize Specification allows you to display and modify the properties and relationships of a use case in the current model.

Specification Content

The Generalize Specification contains the General tab.
