Decision Specification--Swimlanes Tab Decision Specification--Swimlanes Tab
Figure 62 Decision Specification--Swimlanes Tab
Refer to the descriptions in the Introduction to Specifications chapter for information on the specification elements.
Synchronization SpecificationA Synchronization Specification allows you to display and modify the properties and relationships of a synchronization on a statechart diagram or activity diagram.
The Synchronization Specification consists of the following tabs: General and Transitions.
