Dependency Specification--General Tab

Dependency Specification--General Tab

Figure 39 Dependency Specification--General Tab

Refer to the descriptions earlier in this chapter or in the Introduction to Specifications chapter for information on the specification elements.


Has Relationship (Booch Only)

A has relationship shows a whole and part relationship between two classes, where one class is the whole and the other is the part. The whole class contains or owns its parts. This relationship is also called an aggregation relationship.

Because attributes for a class can be expressed by a has by-value relationship with cardinality of "1," attributes are also defined in the has relationship specifications.

To display a has relationship's specification, select any icon representing the has relationship and either double-click or click Browse > Specifications.

Specification Content

The Has Specification consists of the following tabs: General and Detail.
