Operation Specification--Semantics Tab

Figure 30 Operations Specification--Semantics Tab

Refer to the descriptions in the Introduction to Specifications chapter for information on the specification elements not covered in the following section.

Semantics

The action of the operation is shown in this area.

Interaction Diagram

Select an interaction diagram from the list box that illustrates the appropriate semantics.
